Panasonic HC-X1600E - Versatile 4K Camcorder

Discover a New Dimension of Professional Video Production

The Panasonic HC-X1600E camcorder is the perfect choice for anyone looking to capture high-quality moments without compromise. This versatile 4K camcorder delivers stunning image quality, intuitive operation, and advanced features to bring every creative idea to life. Whether you're using it for professional projects or personal hobbies, the HC-X1600E ensures that your results are always professional and impressive.

Record high-quality UHD 4K60 video and still photos virtually anywhere with the Panasonic HC-X1600 UHD 4K Camcorder, thanks to its lightweight and compact body. Whether you're filming behind the scenes of a music video or getting content for your latest social media project, the HC-X1600 can work as both a main or secondary camera. The camcorder features a 1/2.5" 8.29MP MOS sensor with versatile recording modes. It is also capable of live streaming up to 1080p video over multiple protocols.

Versatile Recording

The HC-X1600 shoots up to UHD 4K60 video using MOV, MP4, and AVCHD codecs. It also supports a high bit rate of 200 Mb/s when recording UHD 4K at 59.49/50p with HEVC codec or with Full HD 120/100 fps Super Slow Motion. The integrated 25mm lens reaches a 600mm telephoto focal length and provides a wide viewing angle. Capture close-up details using the 24x optical zoom or the 48x digital i.ZOOM in Full HD resolutions.

Live Streaming, Wireless Control

Built-in dual-band Wi-Fi connectivity allows you to live stream footage directly to sources of your choice. The camera supports RTSP, RTP, RTMP, and RTMPS protocols. It can stream Full HD resolution video in both unicast and multicast formats. Connect to the HC ROP app on a tablet or smartphone for remote control and live image preview.

Interface and Connectivity

An HDMI output port delivers UHD 4K video to a source of your choice. Record directly to two SD cards simultaneously in MOV/MP4 formats. An integrated stereo microphone captures 48 kHz 16-bit audio in AVCHD/MP4 formats and 48 kHz 24-bit audio in MOV formats. Add your own microphone using the 3.5mm stereo mini jack or 3-pin XLR input with phantom power support and monitor your overall audio via the headphone jack. An additional audio output for a speaker is also included. Remotely control the camera via a 2.5mm mini jack.

Hybrid OIS, Face Detection Autofocus

Hybrid 5-axis OIS (optical image stabilization) ensures your footage remains stable using both optical and electronic stabilization. A Ball OIS system also improves small-amplitude blurring. High-precision autofocus with face detection technology locks onto subjects for precise focusing while maintaining exposure. Use the articulating 3.5" LCD touchscreen to activate precise tracking and the OLED EVF viewfinder for handheld image monitoring.

ND Filters

The camera features built-in selectable clear, 1/4, 1/16, and 1/64 ND mechanical filters for quick adjustments during changing lighting conditions.

Long Battery Life

A 5900mAh rechargeable battery keeps the camera up and running for up to 6 hours and 10 minutes of UHD 4K shooting. You can also use the USB-C input to power the camera via DC sources.

Specifications

• Sensor Resolution: Effective: 8.29 Megapixel
• Image Sensor: 1/2.5"-Type MOS
• Image Stabilization: Digital
• Built-In ND Filter: Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
• Capture Type: Stills & Video
• Shutter Type: Electronic Rolling Shutter
• Shutter Speed: 1/8000 to 1/6 Second in Video Mode
• Sensitivity: f/1.8 at 4 lux
• Minimum Illumination: 1.5 Lux
• White Balance: Range: 2000 to 15,000K
• Presets: ATW, Auto
• Focal Length: 4.12 to 98.9mm (35mm Equivalent: 25 to 600mm)
• Optical Zoom Ratio: 24x
• Max Digital Zoom: 2x, 5x, 10x
• Maximum Aperture: f/1.8
• Minimum Aperture: f/4
• Filter Size: 62 mm
• Control Rings: Focus, Zoom
• Focus Control: Autofocus, Manual Focus
• Internal Recording Modes: AVCHD 4:2:0 8-Bit
  1920 x 1080p at 50/59.94 fps
  1920 x 1080i at 50/59.94 fps
  1280 x 720 at 50/59.94 fps
  MOV 4:2:0 10-Bit
  UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps
  MOV 4:2:2 10-Bit
  UHD 4K (3840 x 2160) at 23.98/25/29.97 fps
  1920 x 1080p at 23.98/25/29.97/50/59.94 fps
  1920 x 1080i at 50/59.94 fps
  MOV 4:2:0 8-Bit
  UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps
  MP4 4:2:0 10-Bit
  UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps
  MP4 4:2:0 8-Bit
  UHD 4K (3840 x 2160) at 23.98/25/29.97 fps
  1920 x 1080p at 23.98/50/59.94 fps
• External Recording Modes: 4:2:2 10-Bit via HDMI
  UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps
  1920 x 1080p at 23.98/25/29.97/50/59.94 fps
  1920 x 1080i at 50/59.94 fps
  1280 x 720 at 50/59.94 fps
  720 x 576p at 50 fps
  720 x 480p at 59.94 fps
• Fast-/Slow-Motion Support: Yes
• Built-In Microphone: Stereo
• Audio Recording: AVCHD, MP4 2-Channel 16-Bit 48 kHz
• IP streaming: 264, RTMP, RTMPS, RTP, RTP, RTSP
  1920 x 1080
  1280 x 720
  640 x 360
  320 x 180
• Media/Memory Card Slot: Single Slot: SD/SDHC/SDXC (UHS-I) [512 GB Maximum]
• Video I/O: 1x HDMI (Unspecified Signal) Output
• Audio I/O: 2x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input, 1x 1/8" / 3.5 mm TRS Stereo Microphone Input, 1x 1/8" / 3.5 mm TRS Stereo Headphone Output
• Power I/O: 1x USB-C (9VDC at 3 A) Input
• Other I/O: 1x 2.5 mm Sub-Mini (Remote) Control, 1x USB-C
• Wireless: 2.4 / 5 GHz Wi-Fi, Wi-Fi (802.11a/b/g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
• Mobile App Compatible: No
• Global Positioning (GPS, GLONASS, etc.): No
